MILLHOG Boiler Tube Bevelers

Boilermakers' favorite milling motor since 1954

MILLHOG Water Wall Boiler Tube Replacement System.jpg


MILLHOG Boiler Tube Tools

Renting equipment for the past 65 years, Esco Tool Millhog has been able to observe any potential design flaws and perfect their machines so that they function at the highest level of performance and precision.

MILLHOG Milling Motors


Bevel Boiler Tubes

GSI provides rentals, sales, training and emergency delivery for the Esco Tool MILLHOG brand of portable boiler tube end prep bevelers, or "milling motors". Trusted by boilermakers for over 65 years, the MILLHOG brand has built its name off of durability, reliability and steadfast customer service.

Air-Powered Panel Saws


Remove Waterwall Boiler Tubes

GSI provides rentals, sales, training and emergency delivery for the Esco Tool PanelHOG brand of boiler tube panel air saws. These touch pneumatic abrasive-wheel saws can not only cut away sections of boiler tubes but the same saw can be inverted to remove boiler tube membrane as well.

Splitframe Clamshells

Screenshot (14).png

Cut, Bevel & Counterbore Pipe

GSI is happy to announce the release of Esco Tool's CoHOG brand of portable splitframe clamshell machines for severing, beveling & counterboring pipe in the field. Available with powerful Modec pneumatic motors, Ebinstock electric motors or hydraulic drives, these lightweight yet rigid machines are a breeze to setup and make light work of the toughest heavy-wall pipe applications.



MILLHOG Boiler Tube End-Prep Beveling

Explore the Esco Tool Millhog brand of boiler tube end prep machines. These tried and true milling motors have been the boiler industry standard for over 60 years. Made in the U.S.A., these machines feature Esco's unique dual-opposed tapered roller bearing design which allows them to endure the toughest boiler applications.

GroundHog

0.5" ID - 2.25" OD

The Ground MILLHOG is a right angle, I.D. clamping beveling machine that is only 1.5in (38.1mm) wide and fits between boiler water wall tubes for beveling a single tube and other boiler tube applications with restricted access. The Ground MILLHOG is made of high quality treated materials for durability. Proprietary bearings support heavy duty gears for smooth operation on the toughest applications. Patented push-pull clamp and release system with permanently attached wrenches eliminate the possibility of loose parts separating from the tool. This high performance machine utilizes the EscoLock wedge style blade lock system and TiN coated blades for chatter-free beveling.

Millhog Boiler Tube Beveler

Mongoose

0.625" ID - 3" OD

The Mongoose MILLHOG is a torque free beveling machine for tube and pipe from 0.625” (15.9mm) I.D. to 3.0” (76.2 mm) O.D. and is only 2.25” (57.15 mm) wide which makes it ideal for power station boiler tube work and constrained situations with limited access. Featuring a patented push-pull clamp and release mechanism, it allows the clamps to release from a tube as easily as they tighten. Ideal for beveling, facing and boring on a wide range of tube and pipe alloys, the Mongoose has dual opposed tapered roller bearing and employ the rigid EscoLock blade locking system; which provides chatter-free performance and produces a thick chip without cutting fluids.

Millhog Boiler Tube Beveler

Tube Weasel

0.75" ID - 3" OD

The boilermaker proven Tube Weasel MILLHOG performs precision bevels for accurate weld fit-up and fits a 2.75" (69.9mm) wide opening. Extremely durable, it features a right angle gear drive system which incorporates dual opposed tapered roller bearings. This compact tube beveling tool can be powered by pneumatic, electric or battery motors that are easily interchanged and equally powerful. The Tube Weasel MILLHOG uses the EscoLock cutter blade locking system that securely holds the cutter blade in the cutterhead. Cutter blades have a radical chip breaker that directs the chip away from the tubes surface and minimizes heat build-up.

Screenshot (206).png


C-Hog

0.5" ID - 3" OD

The C-Hog Beveling machine securely attaches to the tube O.D. with a huge clamp that minimizes chatter and vibration and is well suited for small bore tubes because there is no I.D. clamp or mandrel to interfere. The I.D. clearance gained also allows for large, tough I.D. boring blades that increase Cutter Blade endurance. Designed for maximum operator comfort, efficiency and ease of use, the C-Hog’s attached feed wrench lets the operator comfortably feed the tool as it bevels the tube with minimal fatigue. Constructed to deliver reliable performance on the toughest applications, the C-Hog is a rugged tool that is light weight and compact. Highly engineered, it incorporates state of the art materials and heat treated components.

Screenshot (207).png

HHB-5000 MILLHOG

0.45" ID - 2.25" OD

MILLHOG High speed tube bevelers feature a pilot locating system that automatically centers the tool on the tube. Simple to operate, just insert the pilot into the I.D., squeeze the throttle and finish your end prep completely in as fast as 3 seconds. The high speed cutting action creates no reaction torque, even if the tool is stalled. Straight models can be hand-held or used with the track chassis and post assembly. With this option bevel height is controlled with the adjustable depth stop and ensures all bevels are exactly the same height, saving valuable fit-up time. Right angle models are ideal for applications with height restrictions.

Screenshot (208).png

HHB-10000 MILLHOG

0.45" ID - 4" OD

MILLHOG High speed tube bevelers feature a pilot locating system that automatically centers the tool on the tube. Simple to operate, just insert the pilot into the I.D., squeeze the throttle and finish your end prep completely in as fast as 3 seconds. The high speed cutting action creates no reaction torque, even if the tool is stalled. Straight models can be hand-held or used with the track chassis and post assembly. With this option bevel height is controlled with the adjustable depth stop and ensures all bevels are exactly the same height, saving valuable fit-up time. Right angle models are ideal for applications with height restrictions.

Screenshot (209).png


Wart Hog

0.75" ID - 4.5" OD

The Wart Millhog is a portable right angle I.D. clamping pipe and tube beveling machine that features an efficient low maintenance design. Incorporating a gear drive that is fully supported by dual opposed tapered roller bearings and three heavy duty ball bearings. This gives the Wart the backbone to satisfy a wide variety of applications and is a favorite choice among boilermakers and pipe fitters. All components are made of the finest materials and parts subject to wear are heat treated for durability and long use. Sealed construction prevents debris from getting inside the tool, allowing use in any orientation. What's more the compact design requires a minimum of 2.625" to fit between tubes in a boiler tube waterwall.

Screenshot (211).png

FIN MILLHOG

1.25" ID - 2.5" OD

The Fin MILLHOG tube fin removal machine clamps to the tube I.D. and features a patented cutter blade which separates fin from tube O.D. Forget about chipping hammers and grinders! This machine removes 4" / 101.6mm of fin from a tube O.D. in under 4 seconds. Once the tool is attached to the tube I.D. and the power is activated, the operator advances the rotating cutter and engages the spirally wound fin until the desired amount of fin is removed. The quick action of the rack and pinion feed allows the operator to disengage the feed and clear separated fin from the cutter quickly.

Screenshot (210).png


Pneumatic Panel Saws

Gulf States Industrial also offer rental and purchase pneumatic panel saws for cutting out sections of water-wall tubing in industrial water-tube boilers and removing membrane in between boiler tubes. The same saw can be used on a wrap track to quickly cut pipe in the field.

Boiler Tube Air Saw


Remove Water-Wall Boiler Tubes

The APS-438 MILLHOG is an air-powered saw, that is configured for superb ergonomics, ease of use and operates on a wide variety of materials and applications. MILLHOG air-powered saws have the ability to cut boiler panels, tube, pipe, tanks, sheets and cylindrical structures with ease and leave no heat-affected-zone to fight through in later stages of fabricating. Like all ESCO Tool equipment, functional components are fully supported with precision hardware and conditioned materials for long lasting service and reliability.

Boiler Tube Membrane Bracket

PanelHog Membrane.jpg

Remove Boiler Tube Membrane

The Membrane Bracket slides onto the straight track and the APS-438 or APS-438 LP is mounted for quickly removing membrane from between tubes. The Membrane Bracket track can be set up in two different positions depending on space restrictions.

Wrap Track for Cutting Pipe


Cut Pipe In the FIeld

Wrap tracks are used with the APS-438 LRC or the Universal Pipe Trolley with the APS-438 and APS-438 LP on cylindrical structures such as tube, pipe and tanks from 6.0” (1.8m) - 60.0” (18.3m). Track is easy to setup and can be adjusted/tightened for pipe with varying dimensions. Trolley’s for all saws can also be fine-tuned for smooth motion and firm mounting.



Splitframe Clamshells

Splitframe Clamshells for Cold Cutting & Beveling Pipe

For decades, ESCO Tool has manufactured rugged, reliable and simple to operate tube and pipe fabrication equipment known to the industry as MILLHOG®. Years of working closely with end-users, has led us to develop our own line of split frame machines that hold true to our name. The all new COHOG® split frame eliminates the complication associated with traditional OD mounted tube and pipe fabrication machines while setting a new standard for lasting performance.
At the core of the COHOG® is its uniquely built frame. The stationary ring is machined out of 7075 aluminum alloy, the strongest aluminum obtainable, and hard coated for maximum strength and durability. A full complement of precision-tuned eccentric bearings fully support the rotating ring which is machined from a custom steel forging, heat-treated and nickel-plated for long-lasting corrosion and wear resistance. Self-squaring clamp legs quickly align and secure the machine to the pipe making it rigid enough to part and bevel heavy wall pipe, in one operation, without vibration or chatter. COHOGs feature indexable tool slides and trip mechanisms that use a marked locating system to precisely align and quickly attach without shims or guesswork. A variety of blade modules easily attach to the tool slides and can hold conventional high-speed tool steel blades or cutting inserts. Most cutting inserts have multiple cutting edges, are simple to replace, and provide more cuts per blade at a lower cost.

Esco CoHog Splitframe Clamshell Cold Cutting Pipe Beveling .jpg
